Hongqi Pressure Gauge 4 Inch/ 100mm
petroleum, chemical
machinery and other industrial sectors
Send Inquiry
Chat Now
Product Introduction
Hongqi Pressure Gauge 4 Inch/ 100mm
| Place of Origin | Changxing, Huzhou City, Zhejiang, China |
| Brand Name | Hongqi or as request |
| Dia. Size | 1.5"(40mm),2.0"(50mm),2.5"(63mm),3"(75mm),4"(100mm),6"(150mm) |
| Dial Material | Aluminum |
| Case | Stainless steel |
| Roll ring | Stainless steel or Chromed plated |
| Window | PC or Glass |
| Thread | 1/8",1/4", 3/8",1/2";PT(BSPT,ZG),BSP(G,PF),NPT etc. |
| Bourdon tube: |
Copper alloy or Stainless steel<100Bar: C-Type≥100Bar: Helical Type |
| Connection | Brass |
| Movement: | Brass |
| Range | -20ºC to +60ºC |
| Accuracy | ±1%,±1.6%,±2.5% |
| Mounting type | bottom |
| Filled | glycerine or silicone |
Hot Tags: hongqi pressure gauge 4 inch/ 100mm, suppliers China, manufacturers, factory, brands, wholesale, low price, cheap, made in China, 0 40MPa pressure gauge, 150mm Vibration resistant pressure gauge, 100mm liquid filled pressure gauge, Anti vibration Pressure Gauge, shake resistance pressure gauge for machine, Liquid filled Gauge
