Thread Connection Pressure Gauge With Electric Alarm

Thread Connection Pressure Gauge With Electric Alarm

A thread connection pressure gauge is an essential tool for measuring pressure in various industrial applications. These gauges are known for their accuracy and reliability, making them a popular choice in the industry.

One of the key advantages of a thread connection pressure gauge is its ease of installation. The threaded connection allows for quick and easy attachment to a pipeline or other pressure-containing equipment. This convenience eliminates the need for additional fittings or adapters, reducing the risk of leaks and other safety hazards.

Another significant benefit of using a thread connection pressure gauge is its durability. These gauges are typically made from high-quality materials that can withstand harsh industrial environments. They are designed to withstand extreme temperatures and pressure fluctuations, ensuring accurate readings even in the harshest conditions.

Application Description

It is applied for those gaseous or liquid which neight corrode copper alloys nor explode, nor crystallize. If the gauge is liked with the corresponding electric equipment, it will

realize double controlling to the maximal pressure measurement and minimal pressure measurement.

This gauge have the function of measuring and controlling, and can set the up limit and down limit pressure value. And the measurement was reliable. This gauge is well  suited

for the oil industry and chemical industry and power station and usually is link with the electirc equipment.

Product Description

Nominal size63mm

Accuracy class±2.5%

Display: single or compound scale, variable pressure units including kPa and MPa

InstallationLower mount or back mount

Connectioncustomized

DialAluminum

Contact power: 30VA

Maximal votage: 220V D.C OR 380V A.C

Scale Ranges

It can function like pressure gauge (0 to 100 MPa), vacuum gauge (-0.1 to 0 MPa) and combined pressure gauge (-0.1 to 3 MPa). Prior to usage, specific range should be selected in accordance with specific pressure requirement.

Working Condition

Working temperature：-20 to 60℃

Permissible humidity：No more than 85% of relative humidity
