Name: Explosion-proof Design Housing Pressure Gauge Manufacturers and Suppliers China - Wholesale from Factory - Hongqi Instrument
Brand: Hongqi
SKU: 162969951

Oxygen pressure gauge Y-50

Can measure water, liquid, steam plastic case explosion-proof design general pressure gauge

Product name	General pressure gauge
Product features	Accurate and durable
Accuracy class	1.6% or 2.5%
Case material	Black painted steel
Diameter size	See the picture
Operating pressure	75% of the scale value
Over pressure limit	25% of full scale value
Ring	painted steel
Bourdon Tube	Phosphor Bronze
Socket	Brass
Movement	Phosphor Bronze
Dial	Aluminum, black & red graduation on white background
Pointer	Aluminum, black
Window	sheet glass, PC
Standard Scale	MPa, Kg/cm2, psi/kPa, bar...customized
Connection	1/8", 1/4", 1/2" NPT, BSP, G, M20*1.5(customized)

Can be customized

Application: Chemical and petrochemical industries, conventional and nuclear power plants, pumps, hydro-cleaning machines, presses, engine compressors, turbines, diesel engines and refrigerating plants, food and beverage, pharmaceutical industries. For measuring water, oil, gas or any medium not corrosive to brass or phosphor bronze.

General pressure gauge can be applied for gasesous or liquid media that will not explode, crystallise or freeze, and corrode copper or copper alloy.

Hongqi Instrument (Changxing) Co., Ltd. is a manufacturer with 600 employees; it was established in 2007, Located in No. 199, Baixi Road, Economic Development Zone, Changxing County, Huzhou City, Zhejiang Province, China. The company occupies an area of more than 57000 square meters, They have passed ISO9001, ISO14001 and ISO45001 and CE certification, The company has successful foreign trading experience in Europe, North America, Mideast, Africa and Asia.

Hongqi Instrument Co., Ltd is a professional manufacturer of all kinds of high quality gauges instruments.Our main product lines include dry gauge, liquid filled pressure gauge, special pressure gauge, capsule gauge, stainless steel liquid filled pressure gauge, thermometer, accessories..Our vision and strategy is to become the leading industrial instrumentation manufacturer for pressure gauge and temperature measurement. We will be distinct itself from competitors by offering a diversified and high quality product line, superior customer service, and a global distribution network...

Can measure water, liquid, steam plastic case explosion-proof design general pressure gauge (1)
