Industrial-grade Bi-metal Thermometer

Bimetal thermometer is a measuring gauge which used bimetal piece as sensor part.widely used in machinery, chemical textile, medicnery,foodstuffs, vessel, for measuring and controlling the temperature.WSSX series bimetal thermometer can send out the message when the temperature reach or exceed the setting temperature, so it can be used as the electric switch in the temperature adjusting system. Anti-corrosive type adopt the stainless steel material which is suited for the liquids or gases which has medium corrosion. Application WSS WSSX series bi-metal thermometer is the instrument which suit for low or middle temperature measurement. It can be used for temperature measurement for gas and liquid. The electric contact bi-metal thermometer can measure the temperature Pand when temp exceed the certain value, it can send the controlling signal and alarm.

Specifications

Temperature Range ºC	Model	Mounting Type	Diameter	Stem Diameter	Stem Length	Mounting Thread
-80~40 -40~80 0~50 0~100 0~150 0~200 0~300 0~400 0~500 0~600	WSS-301	Back type	Φ60	Φ6	Stem length between 75mm~3000mm , as customers needs. when length with 1000mm, stem diameter is Φ12, Temperature with 0-50ºC, stem length should ≥150mm	M272 adjustable male thread 2.M272 adjustable female thread 3.M16*1.5 adjustable male thread 4.Inch thread or pipe thread can custom-made.
	WSS-401		Φ100	Φ10
	WSS-501		Φ150
	WSS-311	Bottom type	Φ60
	WSS-411		Φ100
	WSS-511		Φ150
	WSSX-301	Electric contact back type	Φ60	Φ6
	WS-71		Φ60	Φ6
	WSSX-401		Φ100	Φ10
	WSSX-501		Φ150
	WSSX-411	Electric contact bottom type	Φ100
	WSSX-511	Electric contact bottom type	Φ150

Using and Maintenance

The stem length for inserting into measured medium should longer than temperature-sensing element, Ordinary the insert length should longer than 100mm, when temp is 0-50ºC, the insert length should longer than 150mm, so that can ensure the accuracy.
In the process of storage, using and transportation, the stem should avoid impact, Don't make the stem bending deformation and don't use the case as wrench.
Bi-metal thermometer is not suitable for measure the medium temp in open type container. Electric contact type is not suitable to use in the environment which have big vibration.
Bi-metal thermometer should routinely inspect, It is advisable to general inspection once every 6 months.
Electric contact bi-metal thermometer is not allow to working in the big vibrated environment, in case to effect the reliable of the product.
