Shockproof Glycerine Filled Pressure Gauge

Basic Information

Type: General pressure gauge

Display: pointer

Structure: fluid column pressure gauge

Function: Local indication type

Characteristics of measuring medium: corrosion resistance

Liquid: Glycerin, Silicone

Window: Polycarbonate

Movement: stainless steel

Thread: BSP, NPT, metric or other specifications

Ring: stainless steel

Measuring range: medium pressure gauge

Accuracy: 1.6

Scope of application: industrial, civil

Connection: radial

Installation structure: direct installation

Indicative pressure reference: absolute pressure gauge

Case: Stainless steel

Quality: 100% inspection

To: Ships around the world

Burton tube: brass

Hands and dials: aluminum

Transport packaging: single bubble bags and boxes, export cartons, Pierre

Product Description

Product Name:Liquid filled Pressure Gauge

Normal Size:1.5"(40mm),2.0"(50mm),2.5"(63mm),

3"(75mm),4"(100mm),6"(150mm).

Pressure Range:-1Bar(-30"Hg)-0-1000Bar(15000Psi)

Accuracy: ±1%,±1.6%

Operating temperature: -20°C to +60°C

Case:Stainless steel

Bezel:Stainless steel

Bourdon tube:Copper alloy or Stainless steel

<100Bar: C-Type

≥100Bar: Helical Type

Connection:Brass

Movement:

 Stainless steel

Dial:

 Aluminum

Pointer:Aluminum

Window:Polycarbonate or Glass

Thread:

 1/8",1/4", 3/8",1/2";

PT(BSPT,ZG),BSP(G,PF),NPT etc.

Gaskets Filling cap:Nitrile or Silica gel

LiquidGlycerin,silicone
