Bar Manometer
video
Bar Manometer

Bar Manometer

Bar Manometer Brand:HONGQI Gauge Outside Diameter:40mm About1.6inch Bottom entry Copper alloy wetted parts Black ABS or painted steel case
Send Inquiry
Chat Now
Product Introduction



Bar Manometer (CHINA HONGQI INSTRUMENT)

Bar manometer, a device used to measure pressure, is an essential tool in many industries. It helps to monitor and control pressure in various systems such as manufacturing, chemical processing, and HVAC (heating, ventilation, and air conditioning) industries.

Bar manometers come in different types, including digital, analog, and mechanical. They all work in a similar way, with a pressure-sensitive component that converts the pressure being measured into a readable output. This output is usually in units of pressure, such as bars, psi, or kPa.

The importance of bar manometers lies in their ability to ensure the safety and efficiency of the systems in which they are used. For example, in the manufacturing industry, bar manometers are used to monitor the pressure of boilers, steam generators, and other critical systems. This helps to prevent accidents caused by pressure build-up and ensures that the system is operating within safe limits.

In the chemical processing industry, bar manometers are used to monitor and control pressure in pipelines, reactors, and other process equipment. It helps to maintain the desired pressure level during chemical reactions and prevent any pressure-related accidents. Additionally, bar manometers are used in the HVAC industry to control the pressure of air and fluids being transported through ducts and pipes.

Overall, the bar manometer plays a vital role in ensuring the safe and efficient operation of various systems in different industries. It is a versatile and reliable tool that can help to prevent accidents, save energy, and improve productivity. It is crucial for businesses to invest in quality bar manometers and ensure they are calibrated regularly to maintain their accuracy and reliability.

SPECIFICATIONS

Accuracy 2.5%, 1.6%, 1.0%
Ambient temperature -40°C to +65°C
Process temperature Max 100°C (Dry)
Operating pressure 75% of the scale value
Over pressure limit 25% of full scale value
Case Painted steel Or Plastic Case
Ring painted steel
Bourdon Tube Phosphor Bronze
Socket Brass
Movement Phosphor Bronze
Dial Aluminum, black & red graduation on white background
Pointer Aluminum, black
Window sheet glass, PC
Standard Scale MPa, Kg/cm2, psi/kPa, bar...customized
Connection 1/8", 1/4", 1/2" NPT, BSP, G, M20*1.5(customized)

Features:

1.   1/4 BSPT back connection.

2.   Brass components has good corrosion resistance and durability.

3.   The transparent cover offers clear readings and better protection of the dial.

4.   Good air tightness guarantee the accurate measurement.

5.   Suitable for air, water, oil, gas, and other non-corrosive media.



Specification:

Mounting Thread: 1/4 BSPT

Range: 0-15PSI,0-1Bar / 0-30PSI,0-2Bar / 0-60PSI,0-4Bar / 0-100PSI,0-7Bar / 0-160PSI,0-11Bar / 0-300PSI,0-20Bar (Optional)  0-6Mpa

Product Size: diameter 40mm



Our enterprise may accept consumers order with special requirement for instrument & meter.

Y-40-double-scale-radial-pressure-gauge_01

Y-40-double-scale-radial-pressure-gauge_02

Y-40-double-scale-radial-pressure-gauge_03

Y-40-double-scale-radial-pressure-gauge_04

Y-40-double-scale-radial-pressure-gauge_05

Y-40-double-scale-radial-pressure-gauge_06

Y-40-double-scale-radial-pressure-gauge_07

Y-40-double-scale-radial-pressure-gauge_08

Hongqi Instrument (Changxing) Co., Ltd., established in 1993, is a modern technology enterprise specializing in the R&D, production, sales, and service of pressure and temperature instruments. Located in the "Taihu Lake Lookout County" of Zhejiang Changxing Economic Development Zone, the company currently operates two major production bases in Wenzhou and Changxing. Covering an area of 38,000 square meters with over 500 employees, its products are distributed nationwide. Domestically, it has 21 offices and hundreds of agency sales outlets, while also exporting to over a dozen countries and regions in Europe, the Middle East, and East Asia.
