Reliable membrane box pressure gauge

Reliable membrane box pressure gauge

Quick Details

• Place of Origin: Zhejiang, China (Mainland)

• Brand Name: HONGQI

• Model Number: YE-100

• Product Name: theca case pressure gauge

• Movement: brass

• Connection thread: M20 NPT1/2 * 1.5 G1/2 ZG1/2, and so on

• Shell: Aluminum

• Accuracy degree: 2.5%

• Measuring unit: kpa

• Measuring range: 0 ~ 1.6... 60 kpa

• Bellows: brass, 316

• Joint: HPb59-1

• Using the environment temperature:-25℃~55℃

This gauge adopt capsule as the sensitivity part, can measure the micro-pressure or negative pressure of the gases which have no corrosion function to the copper alloys and have no explosion And it is widely used in boiler ventilation, gas tube and fuel setting and so on.
This gauge is made up of the measuring system (invole connector,capsule), gear setting, pointsetting,and outer case.
When the pressure of the medium act on the capsule, and make it moving, with the help of the stick and magnified. the pointor point out on the dial.
Working positon, environment: the gauge should be installed vertically, working temprature is -25℃-55℃, relative humidity is no more than 80%. and corrosive gases mustn't exisin the ambient environment.emperature effect: when environmental temperature deviates from 20 ±5℃.additional error is no more than 0.4%/10℃
