Dia. 63.80.100.150 Bi-Metal Thermometer
video
Dia. 63.80.100.150 Bi-Metal Thermometer

Dia. 63.80.100.150 Bi-Metal Thermometer

Dia. 63.80.100.150 Bi-Metal Thermometer Special execution according to customer's requirements possible. Mini car, high precision car, refrigerator, mechanical thermometer The movement has strong stability, high accuracy and strong earthquake resistance
Send Inquiry
Chat Now
Product Introduction



Dia. 63.80.100.150 Bi-Metal Thermometer



Thermometers for general measurement of positive and / or negative temperature.
Φ Diameter 63mm 80mm 100mm 150mm
Case Steel-chrome-plated,option:St.st
Measuring system Brass,option:St.st.(SS316)
Scale range -60ºC ~+600ºC
Connection thread brass G1/4",G1/8" NPT; BSPT.Option:St.st.(ss 316)
Connection Bottom,back centre
Lens Glass
Dial Aluminium-white
Pointer Aluminium-black
Ring Steel-chrome-plated
Options Front flange
Stem 45mm,63,…at inpuiry
Special execution according to customer's requirements possible.
Mini car, high precision car, refrigerator, mechanical thermometer
The movement has strong stability, high accuracy and strong earthquake resistance

63mm-tube-wall-thermometer-2_01

63mm-tube-wall-thermometer-2_02

63mm-tube-wall-thermometer-2_03

63mm-tube-wall-thermometer-2_04

63mm-tube-wall-thermometer-2_05

63mm-tube-wall-thermometer-2_06Welcome to call us to learn more.
